FMUSER Economic FM Radio Station Studio Package 50w FM transmitter 3-8 Kilometers

FMUSER Economic FM Radio Station Studio Package 50w FM transmitter 3-8 Kilometers This is a relative complete package for FM Radio Station, including the studio part and transmission part. By using the 350w FM transmitter, with a high gain FM Dipole antenna, it can broadcast about 3-8 kilometers distance in good environment.  The package includes following items: 1* 350W FM Transmitter           Features: * 1 U-standard chassis * Have the standing wave protection, and overtemperature protection. * Output power from 0.5W ~ 50W continuously adjustable * Show the timely output power and various working sta

Detail

FMUSER has upgraded panel design of all CZE series to FU series, stay tuned for further updates!

Price(USD) Qty(PCS) Shipping(USD) Total(USD) Shipping Method Payment
1463 1 295 1758 DHL



FMUSER Economic FM Radio Station Studio Package 50w FM transmitter 3-8 Kilometers




This is a relative complete package for FM Radio Station, including the studio part and transmission part. By using the 350w FM transmitter, with a high gain FM Dipole antenna, it can broadcast about 3-8 kilometers distance in good environment.


The package includes following items:


1* 350W FM Transmitter


 Features:
* 1 U-standard chassis
* Have the standing wave protection, and overtemperature protection.
* Output power from 0.5W ~ 50W continuously adjustable
* Show the timely output power and various working status.
* Operating frequency: 87 ~ 108MHz
* Output power: 50W MAX continuously adjustable
* Output Impedance: 50 ohm
* Spurious and harmonic radiation:-60db
* Rated working voltage: 200 ~ 240V AC / 50/60Hz
(Electricity Voltage is switchable inside the chassis)

1* Professional FM Dipole Antenna


Electrical specification:
* Frequency range: 88~108 MHz ( 1MHz stepping)
* Input Impedance Impedance:50 ohm
* VSWR <1.5
* Gain:3.5 dBi
* Polarization: Verticality
* Maximum Power Input: 150W
* Horizontal 3dB Beam Width:360 °
* Vertical 3dB Beam Width:73 °
* Mechanical Specifications:
* Height: 990mm
* Radiating Element Material:Aluminum Alloy
* Connector:SL16-K
* Holding Rod Diameter: Φ30~Φ40 mm

1* 20M Coaxial Cable with Connectors


15 meters SYV-50-5 Feeder cable with N male and SL16 male connectors

1*8-way Mixer


Features
FMUSER USB802 8-way mixer
* Ultra-Low Noise Design 8-Input 2-Bus Mixer
* Ultra-low noise design, highest possible headroom, ultra-transparent audio
* 2 state-of-the-art, studio-grade IMP "Invisible" Mic Preamp with 130 dB dynamic range for 24-bit, 192 kHz sampling rate inputs
* Effective, extremely musical 3-band EQ on all channels
* 6 balanced high-headroom line inputs
* One post fader FX send per channel for external FX devices
* One stereo aux return for FX applications or as separate stereo input

2*Monitor Headphone




Feature
AKG44 Monitor headphone
* Wear mode: wearing ear
* Headphones Type: Wired
* Whether the microphone: No
* Headset service: Genius
* Frequency response 18-20000Hz
* impedance of 32 Ohms
* SPL 115 dB SPL / V
* harmonic distortion: <1%, maximum
* input power of 200mW
* leather earmuffs, automatic adjustableand comfortable headset
* lightweight form factor
* Back retractable headphones
* excellent cost performance

2* Monitor Speaker


Feature
Monitor Speakers FMUSER FU200MKIII
* Bass is 5.25 inch magnetic steel tape
* 1-inch tweeter with magnetic
* Power 50w
* Peak power 70w
* Physical divider
* Treble independent regulation
* Bass independent regulation
* All wooden box 9mm thick planks
* Rated voltage 220v or 110V


1* Audio Processor


Feature
FMUSER FU1600
* Reference-Class 2-Channel Expander/Gate/Compressor/Peak Limiter with Integrated Dynamic Enhancer, De-Esser and Low Contour Filter
* Switchable IKA (Interactive Knee Adaptation) program-adaptive compression circuitry combines the advantages of hard-knee and soft-knee characteristics
* Adjustable dynamic Enhancer with level meter for brilliant, lively audio even with heavy compression
* IGC (Interactive Gain Control) peak limiting circuitry combines clipper and program limiter for reliable and inaudible protection against signal peaks
* Switchable De-esser removes excessive sibilance from your vocal tracks
* IRC (Interactive Ratio Control) expander/gate circuitry for virtually inaudible noise suppression
* Automatically or manually adjustable attack and release times

2* Microphone

Feature
* Product Name: FMUSER FU-350
* Brand: FMUSER
* Tuner Type: Dynamic
* Wireless: Wired
* Channel: 1
* Pointing characteristics: Cardioid

2* Microphone Stand


Feature
* Four external springs
* Cantilever fastening knob
* Upper two tubes, the lower three tubes, increase stability
* Can be used for horizontal and vertical installation
* Hollow stent may be passing through the cable from the boom
* Chassis Mount Standard accessories

2* BOP cover

Feature
* Large double filter
* Broadcast Recording
* Microphone BOP cover






FMUSER has upgraded panel design of all CZE series to FU series, stay tuned for further updates!







Price(USD) Qty(PCS) Shipping(USD) Total(USD) Shipping Method Payment
1463 1 295 1758 DHL
